Installation Instructions for Motorcycle Front Fork Suspension Damper Oil Seal Dust Cover 43x54x11

Compatibility:
This dust cover is compatible with D models including 620, 696, 696 Plus, 748S, and 748. Please ensure your motorcycle model matches before installation.

Tools Required:

1. Screwdriver (Phillips and Flat-head)
2. Socket Wrench Set
3. Torque Wrench
4. Pliers
   5.Clean Cloth
5. Grease (for lubrication)
6. Pick tool (optional, for difficult seals)

Installation Steps:

1. Preparation:

   • Place your motorcycle on a stable, flat surface.
   • Use a motorcycle stand to lift the front end for easier access to the fork components.

2. Remove the Forks:

   • Use a socket wrench to disconnect the front wheel from the motorcycle.
   • Unscrew and remove the front forks (consult your motorcycle’s manual for specific instructions).

3. Clean the Area:

   • Wipe down the area around the oil seal and ensure there is no dirt or debris. Use a clean cloth for this purpose.

4. Remove the Old Dust Cover:

   • Carefully pry off the old dust cover using a screwdriver or pick tool to avoid damaging the fork tube.

5. Install the New Dust Cover:

   • Place the new dust cover onto the fork, ensuring it fits snugly into place.
   • Apply a small amount of grease around the seal for added protection and ease of movement.

6. Reassemble the Forks:

   • Reinsert the forks back into the motorcycle frame.
   • Reattach the front wheel and tighten all screws and bolts to the recommended torque specification using the torque wrench.

7. Final Check:

   • Double-check all connections and ensure the dust covers are properly seated.
   • Lower the motorcycle from the stand and perform a gentle test to ensure everything is functioning properly.

Note:
Always refer to your motorcycle’s manual for specific torque settings and assembly instructions. If you experience any difficulty during installation, consider seeking professional assistance.

Enjoy the enhanced performance and protection the new dust cover provides for your motorcycle!
