Product Installation Instructions for 5 Pin AC Box Igniter Commutator Trigger Ignition Switch

Compatible Models:

This ignition switch is compatible with a variety of 50-110CC motor vehicles, including dirt bikes, ATVs, and scooters.

Tools Required:

To ensure a smooth installation process, please prepare the following tools:

1. Screwdriver Set (Flathead and Phillips)
2. Wrench Set (Adjustable or specific size)
3. Pliers
4. Wire Strippers (if necessary)
5. Electrical Tape or Heat Shrink Tubing (for securing connections)
6. Multimeter (for testing connections, optional)

Installation Steps:

1. Safety First:

   • Ensure the vehicle is turned off, and the key is removed from the ignition switch.

2. Remove the Old Ignition Switch:

   • Locate the current ignition switch on your vehicle.
   • Disconnect any wires connected to the old ignition switch, taking note of their placements.
   • Use the screwdriver to remove any screws holding the ignition switch in place, and carefully take it out.

3. Prepare the New Ignition Switch:

   • Unbox the new 5 Pin AC Box Igniter Commutator Trigger Ignition Switch.
   • Compare the wiring harness of the new switch with the old one to ensure compatibility.

4. Connect the New Ignition Switch:

   • Connect the wires of the new ignition switch to the corresponding wires in your vehicle, following any notes taken during the removal process.
   • Use electrical tape or heat shrink tubing to secure the connections for safety.

5. Secure the Ignition Switch:

   • Once all connections are made, position the ignition switch in place.
   • Use the screwdriver to mount the new ignition switch securely.

6. Testing:

   • Reconnect the battery if it was disconnected.
   • Turn on the ignition to test the new switch and ensure the engine starts smoothly.

7. Finalize Installation:

   • Make sure all wiring is neatly arranged and secured to prevent any interference during operation.
   • Replace any panels or coverings that were removed during the installation process.

Conclusion:

This 5 Pin AC Box Igniter Commutator Trigger Ignition Switch is designed for ease of installation and reliability. Follow these steps carefully to enjoy enhanced performance and safety on your vehicle. If you encounter any issues, consult a professional for assistance.
