Motorcycle Speedometer Drive Gear Installation Instructions

Compatibility:
This speedometer drive gear is compatible with various motorcycle models, including:

• XL350R (1984-1985)
• XL600R (1983-1987, 1989-1990)
  -XL300R

Tools Required:

• Socket wrench set (including appropriate size sockets)
• Screwdriver (flathead and Phillips)
  -Torque wrench
  -Pliers
  -Clean rags
• Grease or lubricant (optional)

Installation Steps:

1. Preparation:

   • Make sure your motorcycle is on a stable surface.
   • Disconnect the battery to avoid any electrical issues.

2. Remove the Wheel:

   • Use the socket wrench to loosen the bolts securing the front or rear wheel (depending on the model).
   • Carefully lift the motorcycle and remove the wheel.

3. Access the Speedometer Drive:

   • Locate the speedometer drive gear on the wheel hub or transmission.
   • Use the screwdriver or pliers to remove any covers or clips that may be obstructing access to the speedometer drive.

4. Remove the Old Speedometer Drive Gear:

   • Carefully unscrew and remove the old speedometer drive gear.
   • Clean the area to ensure no debris remains that might interfere with the installation.

5. Install the New Speedometer Drive Gear:

   • Position the new speedometer drive gear in the same location as the old one.
   • Secure it in place with the screws or clips, ensuring it is fitted snugly.

6. Reinstall the Wheel:

   • Place the wheel back on the motorcycle.
   • Tighten the bolts using the socket wrench, and follow up with a torque wrench to ensure proper specifications.

7. Reconnect the Battery:

   • Once everything is secured, reconnect the battery.

8. Testing:

   • Start the motorcycle and take it for a short ride to ensure the speedometer is functioning accurately.
   • Check for any unusual noises or vibrations during the test ride.

Conclusion:

Following these steps will help you successfully install the Motorcycle Speedometer Drive Gear. Utilize the necessary tools, and don’t hesitate to consult a professional mechanic if you encounter any difficulties. Enjoy your safe and reliable rides!
