Installation Instructions for 90-Degree Throttle Cable Adjuster

Tools Required:

• Phillips screwdriver
• Flathead screwdriver
• Adjustable wrench or pliers
• 10mm socket wrench (if applicable)
• Torque wrench (optional, for precise tightening)
• Clean cloth or rag (for cleaning)

Installation Steps:

1. Preparation:

   • Ensure the motorcycle is on a stable surface and the engine is turned off.
   • Disconnect the battery to avoid any electrical issues.

2. Remove the Old Adjuster:

   • Locate the existing throttle cable adjuster on your carburetor.
   • Using the Phillips screwdriver, remove any screws or bolts holding the old adjuster in place.
   • Carefully detach the old throttle cable adjuster from the carburetor.

3. Clean the Area:

   • Use a clean cloth or rag to wipe down the area around the carburetor. This will help prevent any dirt or debris from entering the system during installation.

4. Install the 90-Degree Throttle Cable Adjuster:

   • Position the new 90-degree throttle cable adjuster in the same location as the old one.
   • Secure it using the screws or bolts you previously removed. Make sure it is aligned properly to ensure smooth operation.

5. Adjust the Throttle Cable:

   • Gently pull the throttle cable to remove any slack, then use the adjuster to set the required tension.
   • Ensure that the throttle opens and closes smoothly without any binding.

6. Reconnect the Battery:

   • Once you are satisfied with the installation, reconnect the motorcycle's battery.

7. Test the Throttle:

   • Start the engine and test the throttle response. Make any final adjustments to the throttle cable if necessary.

8. Final Check:

   • Double-check all connections and ensure everything is secure.
   • If applicable, use a torque wrench to tighten screws or bolts to the manufacturer's specifications.

Note:

• For optimal performance, regularly check the throttle cable condition and adjust as needed.
• If you encounter any difficulties during the installation, consult a professional mechanic for assistance.

Enjoy your improved throttle response and enhanced performance with the new 90-degree throttle cable adjuster!
