Product Installation Instructions for Universal Drive Belt for 50cc Models (1997-1998)

Compatibility:

• Fits 1997-1998 50cc models.
• Compatible with models 709 17.4 28.

Tools Required:

1. Socket set (including 8mm, 10mm, and 12mm sockets)
2. Wrenches (adjustable or standard set)
3. Screwdriver set (Philips and flathead)
4. Pliers
5. Torque wrench (optional but recommended)
6. Work gloves
7. Safety goggles
8. Clean cloth or rag for wiping

Installation Steps:

1. Preparation:

   • Make sure the vehicle is parked on a flat, stable surface.
   • Ensure the engine is cool and the ignition is off.

2. Remove the Cover:

   • Using the appropriate socket, remove the screws or bolts securing the drive cover.
   • Carefully lift off the cover and set it aside.

3. Remove the Old Drive Belt:

   • Take note of how the existing belt is installed for reference.
   • Carefully detach the old drive belt from the clutch and variator.

4. Install the New Drive Belt:

   • Position the new drive belt in the same configuration as the old belt.
   • Slide the belt over the clutch and variator pulleys, ensuring it is seated properly.

5. Reattach the Cover:

   • Carefully place the drive cover back on.
   • Secure it with the screws or bolts, tightening them securely but not excessively.

6. Final Check:

   • Ensure all tools are removed from the installation area.
   • Check for any obstructions or loose components.

7. Test the Vehicle:

   • Start the engine and let it idle for a few minutes.
   • Take the vehicle for a short test ride to ensure proper functionality.

Tips:

• Always wear gloves and safety goggles when working on your vehicle to protect against injuries.
• Refer to your vehicle’s manual for specific instructions related to your model if necessary.

By following these steps, you can easily replace the drive belt and enjoy enhanced vehicle efficiency and performance.
