Installation Instructions for Carburettor Adapter for WR 32 36 DGV DGAV DGEV Manifold Conversion

Introduction:
This Carburettor Adapter is designed for WR 32 36 DGV DGAV DGEV engine models, allowing you to easily upgrade and convert to various carburettor models with optimal performance. Follow these instructions carefully to ensure a smooth installation.

Tools Required:

1. Socket set (including ratchet and extensions)
2. Wrenches (metric sizes)
3. Screwdrivers (both Phillips and flathead)
4. Torque wrench
5. Gasket scraper or putty knife
   6.Cleaning cloth
6. Safety goggles
7. Rubber gloves
8. Engine oil (for lubrication)
9. Carburettor cleaner (optional)

Installation Steps:

1. Preparation:

   • Ensure the engine is cool and disconnect the negative battery terminal to prevent any electrical issues.
   • Gather all necessary tools and materials before starting the installation.

2. Remove the Existing Carburettor:

   • Disconnect the throttle linkage and any electrical connections to the existing carburettor.
   • Unscrew the carburettor from the manifold using the appropriate socket or wrench.
   • Carefully lift the carburettor off and set it aside.

3. Clean the Manifold:

   • Use a gasket scraper or putty knife to remove any old gasket material from the manifold surface.
   • Clean the manifold thoroughly with a cleaning cloth to ensure a proper seal for the new adapter.

4. Install the Carburettor Adapter:

   • Position the Carburettor Adapter onto the manifold.
   • Ensure that it aligns properly with the bolt holes.
   • Apply a thin layer of engine oil to the gasket surfaces for enhanced sealing.
   • Secure the adapter using the provided bolts, tightening them evenly in a crisscross pattern to ensure a good seal.

5. Mount the New Carburettor:

   • Place the new carburettor onto the installed adapter.
   • Align the bolt holes and secure it with the appropriate bolts. Tighten them to the manufacturer's recommended torque specifications using a torque wrench.

6. Reconnect Linkages and Electricals:

   • Reattach the throttle linkage and reconnect any necessary electrical connections.
   • Double-check all connections for security.

7. Final Checks:

   • Inspect the installation for any visible leaks and ensure everything is properly seated.
   • Reconnect the negative battery terminal.

8. Testing:

   • Start the engine and let it idle, checking for proper operation and any unusual sounds.
   • Take the vehicle for a short test drive to evaluate the performance of the new carburettor setup.

Conclusion:
Upon successful installation of the Carburettor Adapter, you should experience improved engine performance and responsiveness. Regularly check for any signs of wear or leakage and maintain your carburettor and adapter for optimal operation.
