Installation Instructions for High Voltage Ignition Set Compatible with 1E40F, 1E40F-3, 1E40FP-3Z

Product Compatibility:
This high voltage ignition set is compatible with various models including 1E40F, 1E40F-3, 1E40FP-3Z, and numerous 42CC and 47CC sprayer models such as 3WF-3, 3WF-2.6, and 650 Knapsack Power Mist-Duster.

Tools Required:

• Screwdriver set (flathead and Phillips)
  -Wrench set
  -Pliers
• Torque wrench (optional)
• Safety goggles
• Work gloves

Installation Steps:

1. Preparation:

   • Ensure the sprayer is powered off and disconnected from any power source.
   • Wear safety goggles and work gloves for protection.

2. Remove the Old Ignition System:

   • Use the appropriate screwdriver to remove screws and access the ignition system.
   • Carefully disconnect the old ignition components, noting their arrangement for reference.

3. Install the New High Voltage Ignition Set:

   • Position the new ignition components into place, ensuring they fit correctly into the designated slots.
   • Connect the ignition wires, ensuring a secure fit (refer to your old ignition setup for guidance).
   • If applicable, use a torque wrench to ensure that screws are tightened to the recommended specifications.

4. Reassemble the Sprayer:

   • Once the new ignition set is installed, reattach any covers or panels that were removed.
   • Make sure all screws and connections are secure.

5. Testing:

   • Reconnect the power source and start the sprayer to test the new ignition system.
   • Observe its performance and ensure it starts smoothly.

6. Final Cleanup:

   • Dispose of any old ignition components properly.
   • Clean the work area and store away all tools used during the installation.

Conclusion:
This high voltage ignition set ensures reliable performance and ease of installation, enhancing the efficiency of your sprayer in various gardening and agricultural applications. If any issues arise during installation, please consult the user manual for your specific sprayer model.
