Installation Instructions for Rear Brake Pads

Compatibility:

This rear brake pad set is compatible with the following motorcycle models:

• Breva
• Nevada 750
• V7
• Cafe Racer 1000
• S01 Corsa V
• 1100 California

Tools Required:

Before starting the installation, ensure you have the following tools ready:

• Socket wrench with appropriate sockets
  -Torque wrench
• Flathead screwdriver
• Phillips screwdriver
• Wire brush (for cleaning)
• Brake cleaner spray
• Safety goggles
• Gloves

Installation Steps:

1. Preparation:

   • Ensure your motorcycle is on a stable surface and the ignition is turned off.
   • Wear safety goggles and gloves for protection.

2. Remove the Rear Wheel:

   • Using the socket wrench, loosen and remove the bolts securing the rear wheel.
   • Carefully pull the rear wheel off the motorcycle and set it aside.

3. Access the Brake Caliper:

   • Locate the brake caliper attached to the rear wheel assembly.
   • Remove the bolts securing the caliper using a socket wrench.

4. Remove Old Brake Pads:

   • Once the caliper is free, gently slide the old brake pads out of the caliper bracket.
   • Inspect the caliper and clean it using a wire brush and brake cleaner spray if necessary.

5. Install New Brake Pads:

   • Insert the new brake pads into the caliper bracket, ensuring they fit snugly and are aligned correctly.
   • Make sure to follow any orientation instructions provided with the brake pads.

6. Reattach the Brake Caliper:

   • Secure the caliper back in place over the new brake pads using the previously removed bolts.
   • Tighten the bolts to the manufacturer-recommended torque specifications using a torque wrench.

7. Reinstall the Rear Wheel:

   • Place the rear wheel back onto the motorcycle, aligning it with the axle.
   • Secure the wheel by tightening the bolts using the socket wrench.

8. Final Checks:

   • Before riding, pump the brake lever a few times to ensure the brake pads seat correctly against the rotor.
   • Check the brake fluid level and ensure it is adequate.

9. Test Ride:

   • Take a short test ride to ensure the brakes are functioning properly.
   • Listen for any unusual noises and check for proper function before heading out on longer rides.

With these instructions, you should be able to successfully install your new rear brake pads, enhancing your motorcycle's braking performance and overall safety. Enjoy your ride!
